Cal-Royal CRPS Power Supply For Electrified Exit Devices
$503.68
$662.74
24% Off
- Model:
-
CRPS
Item normally ships out within 1-2 Weeks (excluding transit time).If out of stock it can take up to 3-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.
Request for Quote - Built to run up to 4 or 8 locks, exit trim, and LP Motor / Solenoid kits
- 4 or 8 independent inputs / outputs
- Linear design insures ample inrush / hold current for latch retraction
- Door mounted LED Power Indicator
- Fire alarm link
- Removable Euro-style terminal blocks allow for easy installation
- No hassle 3-year warranty
- CRPS440B: 4 Solid-State Input / Output (input triggered by dry contact)
- CRPS480B: 8 Solid-State Input / Output (input triggered by dry contact)
- Regulated, independent battery charging
- Automatic uninterrupted backup circuit
- Battery cables included
- Requires (2) 12V DC 7AH batteries
- Batteries not included
- Public Buildings & Facilities
- Commercial & Industrial Buildings
- Government & Military Facilities
- Retail & Strip Malls
- Multifamily & Mixed-Use
- Input Voltage
- 120V AC, 60 Hz, 2 Amp Input Fuse
- Output Voltage
- 24V DC @ 4A
- Power Tap
- 24V DC @ .5A
- Temperature Range
- 0 to 49° C; 32 to 120° F
- Maximum Humidity
- 85%
- LED-RED
- A/C Power indicator
- LED-GREEN
- D/C Output indicator
- LED-ORANGE
- Battery Output Indicator
- Enclosure dimensions
- 13" × 15.5" × 5"
Details: Cal-Royal CRPS Power Supply For Electrified Exit Devices
The CRPS440B and CRPS480B (Battery Backup) are regulated, linear power supplies rated at 4 Amps @ 24V DC to (4) or (8) PTC fused outputs. It also provides (4) or (8) solid-state input triggers, protects system relays from shorts, grounds and surges. These power supplies may also be used to power electrified mortise and cylindrical locks, electric strikes, mag locks, motorized exit devices.
Features
Additional Features (Battery Backup)
Applications
Specifications
