Hafele 329.23.610 Aluminum Frame Door Hinge, Salice, 105D Full Overlay
$5.14
- Model:
-
329.23.610Item normally ships out within 1-2 Weeks (excluding transit time).If out of stock it can take up to 3-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.Request for Quote
Details: Hafele 329.23.610 Aluminum Frame Door Hinge, Salice, 105D Full Overlay
Features
- Developed for use with metal profiles (563.55.931, 563.55.031, 563.55.911)
- A 3.5 × 9.5 mm (6 × 3/8") countersunk sheet metal screw to attach hinge to frame is recommended
Specifications
- Version
- With automatic closing spring
- Concealed hinge version
- full overlay
- Crank type
- Straight
- For door material
- aluminium frame
- Door processing for assembly
- without
- Material
- Cup: Zinc alloy, Hinge arm: Steel
- Color/finish
- nickel plated
- Opening angle
- 105D
- For aluminium frame width
- 17-24 mm
- Cup fixing
- for screw fixing
- Installation
- Door on cabinet with slide-on system A or quick fixing system SM
Applications
- Public Buildings & Facilities
- Commercial & Industrial Buildings
- Government,
- Retail & Strip Malls
- Multifamily & Mixed-Use
