Hafele 329.26.626 Concealed hinge, Salice, 110D Full Overlay
$26.47
- Model:
-
329.26.626Item normally ships out within 1-2 Weeks (excluding transit time).If out of stock it can take up to 3-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.Request for Quote
Details: Hafele 329.26.626 Concealed hinge, Salice, 110D Full Overlay
Features
- Multi-talent: makes wide range of installations possible with rounded, rebated and profiled doors
- Anti-slip protection against accidental finger trapping
Specifications
- Version
- With automatic closing spring
- Concealed hinge version
- full overlay
- For door material
- wood, Profile doors
- Material
- Zinc alloy
- Color/finish
- nickel plated
- Opening angle
- 110D
- Cup drilling depth
- 9 mm
- Drilling pattern
- 45/9.5
- Adjustment facility
- Side adjustment from -1.5 to +4.5 mm height adjustment from -2 to +2 mm depth adjustment with Duomatic A mounting plates +2.8 mm, with Duomatic SM mounting plates from -0.5 to +2.8 mm
- Installation
- Door on cabinet with slide-on system A or quick fixing system SM
Applications
- Public Buildings & Facilities
- Commercial & Industrial Buildings
- Government,
- Retail & Strip Malls
- Multifamily & Mixed-Use
