Hafele 329.35.520 Salice, Blind Corner Concealed Hinge, 110 Degree Opening Angle, Nickel-Plated
$7.98
- Model:
-
329.35.520
Item normally ships out within 1-2 Weeks (excluding transit time).
If out of stock it can take up to 3-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.
Request for Quote
Details: Hafele 329.35.520 Salice, Blind Corner Concealed Hinge, 110 Degree Opening Angle, Nickel-Plated
Specifications
- Area of application
- Blind corner
- Version
- With soft closing mechanism
- Concealed hinge version
- blind corner application
- Crank type
- Straight
- For door material
- wood
- Door processing for assembly
- with cup drilling
- Material
- Cup - Steel, Hinge arm - Zinc alloy
- Color/finish
- nickel plated
- Opening angle
- 110 degree
- Cup drilling depth
- 11.00 mm
- Cup drilling Dia
- 35.00 mm
- Cup fixing
- For mounting in drilled hole
- Drilling pattern
- 45/9.5
- Installation
- Door on cabinet with slide-on system A or quick fixing system SM
