Sloan WETS-200 ST-2009 Standard Height Toilet Fixture w/ Sloan Flushometer

Name: Sloan WETS-200 ST-2009 Standard Height Toilet Fixture w/ Sloan Flushometer
Brand: Sloan Valve Co.
SKU: WETS-200
Price: 338.25 USD
Availability: InStock

$338.25

$520.39

35% Off

Model:: WETS-200

Item is normally in stock and ships out within 2-3 Business days (excluding transit time).

If out of stock it can take up to 2-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

Request for Quote

Email us your RFQ sales@americanwholesaleoutlet.com
or call us for pricing 215-279-8511
or send us a request using the form below and we will respond to you by email.

Product Name

SKU

Ask A Question

Details: Sloan WETS-200 ST-2009 Standard Height Toilet Fixture w/ Sloan Flushometer

Fixture Features

White Vitreous China
Elongated bowl
Floor mounted, floor outlet
Siphon jet flushing action achieves 1000g Map score when used with any Sloan flushometer
Water spot area: 10⅛" × 9⅜" (26 cm × 24 cm)
1½" I.P.S. top spud inlet
2⅛" fully glazed trapway
Closet bolts and caps included
Toilet seat not included
Static load rating of 1000 lbs. (See Notes)
WaterSense compliant when used with a WaterSense compliant
flushometer

Flushometer Features of Sloan 111-1.28 DFB

High Chloramine Resistant PERMEX® Synthetic Rubber DFB Dual Filtered Bypass Diaphragm
1" I.P.S. Screwdriver Bak-Chek® Angle Stop with Stop Cap
Vacuum Breaker with Flush Connection
Spud Coupling and Spud Flange for 1-1/2" Top Spud
Sweat Solder Adapter with Cover Tube and Cast Wall Flange
Non-Hold-Open Handle and No External Volume Adjustment to Ensure Water Conservation
Diaphragm, Handle Packing and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine Resistance
ADA Compliant Metal Oscillating Non-Hold-Open Handle

Flushometer Features of Sloan 111-1.28 L/ST

Vacuum Breaker with Flush Connection
Spud Coupling and Spud Flange for 11⁄2" Top Spud
Sweat Solder Adapter with Cover Tube and Cast Wall Flange
Non-Hold-Open Handle and No External Volume Adjustment to Ensure Water Conservation
Diaphragm, Handle Packing and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine Resistance
ADA Compliant Metal Oscillating Non-Hold-Open Handle
High Chloramine Resistant PERMEX® Synthetic Rubber DFB Dual Filtered Bypass Diaphragm

Flushometer Features of Sloan 8111-1.28

PERMEX® Synthetic Rubber Diaphragm with Dual Filtered Fixed Bypass
Sweat Solder Adapter with Cover Tube and Cast Wall Flange
1" I.P.S. Screwdriver Bak-Chek® Angle Stop with Vandal Resistant Stop Cap
Spud Coupling and Spud Flange for 1 1/2" Top Spud
"Low Battery" Flashing LED
No External Volume Adjustment to Ensure Water Conservation Economical
Stop Seat and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine resistance
Infrared Sensor with Multiple-focused, Lobular Sensing Fields for high and low target detection
Engineered Plastic Cover with replaceable Lens Window
Courtesy Flush® Override Button
Four (4) Size AA Batteries included

Flushometer Features of Sloan 111-1.28 ESS

Vacuum Breaker with Flush Connection
Sweat Solder Adapter with Cover Tube and Cast Wall Flange
User friendly three (3) second Flush Delay
No External Volume Adjustment to Ensure Water Conservation
OPTIMA® EL-1500 Self-Adaptive Infrared Sensor with Indicator Light
I.P.S. Screwdriver Bak-Chek® Angle Stop with Vandal Resistant Stop Cap
Courtesy Flush® Override Button
High Chloramine Resistant PERMEX® Synthetic Rubber Diaphragm with Dual-Filtered Fixed Bypass Diaphragm
Diaphragm, Stop Seat and Vacuum Breaker to be molded from PERMEX® rubber compound for Chloramine resistance

Flushometer Features of Sloan 111-1.28 ESS TMO

Flush volumes start as low as 1.6 gpf/6.0 Lpf
Courtesy FlushTM Non-Hold-Open True Mechanical Override
Water conservation is aided by the ADA-compliant, non-hold-open handle, which prevents toilet from exceeding intended flush volume
Integrity of the product is maintained with the vandal-resistant stop cap
Durability is facilitated with high copper, low zinc brass castings for dezincification resistance
Adjustable tailpiece to accommodate different height requirements
Dual-Filtered Fixed Bypass Diaphragm
Valve body, Cover, Tailpiece and Control Stop shall be in compliance with ASTM Alloy Classification for Semi-Red Brass
Valve shall be in compliance to the applicable sections of ASSE 1037.

Flushometer Features of Sloan 111-1.28 SFSM

True Mechanical Override Flush Button
Four (4) size C batteries included
"Low Battery" Flashing LED
"User in View" Flashing LED
72-Hour Sentinel Flush
1" I.P.S. Screwdriver Bak-Chek® Angle Stop with Vandal Resistant Stop Cap
Sweat Solder Adapter w/Cover Tube and Cast Wall Flange with Set Screw
No External Volume Adjustment to Ensure Water Conservation
Stop Seat and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine resistance

Flushometer Features of Sloan WES 115

Lifting Handle UP initiates reduced flush (1.1 gpf/4.2 Lpf), eliminating liquid and paper waste, saving a 1⁄2-gallon of water
Pushing Handle DOWN initiates full flush (1.6 gpf/6.0 Lpf), eliminating all waste
Metal Non-Hold-Open Handle with Triple Seal Handle Packing
Sweat Solder Adapter with Cover Tube & Cast Wall Flange with Set Screw
Non-Hold-Open Handle, Fixed Metering Bypass and No External Volume Adjustment to Ensure Water Conservation Diaphragm
Handle Packing and Vacuum Breaker to be molded from PERMEX® Rubber Compound for Chloramine Resistance
Includes two (2) adhesive backed Metal Wall Plates etched with Instructions

Flushometer Features of Sloan 111-DFSM

Non-Hold-Open True Mechanical Override Full Flush/Dual Flush Buttons
If the user is present for less than one minute and leaves the sensing zone or chooses the small GREEN override button, a reduced flush initiates (1.1 gpf/4.2 Lpf) eliminating liquid and paper waste, saving 1/2 gallon of water
If the user is present for greater than one minute and leaves the zone or chooses the large BLACK override button, the full flush initiates (1.6 gpf/6.0 Lpf) eliminating solid waste and paper
Four (4) size C batteries included
"Low Battery" Flashing LED
"User in View" Flashing LED
72-Hour Sentinel Flush
1" I.P.S. Screwdriver Bak-Chek® Angle Stop with Vandal Resistant Stop Cap
Sweat Solder Adapter w/Cover Tube and Cast Wall Flange with Set Screw
No External Volume Adjustment to Ensure Water Conservation
Handle Packing, Main Seat, Stop Seat and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine resistance
ADA Compliant Battery Powered Infrared Sensor for automatic "Hands- free" operation
PERMEX® Synthetic Rubber Diaphragm with Linear Filtered Bypass and Vortex Cleansing Action

Flushometer Features of Sloan 111-1.6

High Chloramine Resistant PERMEX® Synthetic Rubber Diaphragm with Linear Filtered Bypass and Vortex Cleansing ActionTM
1" I.P.S. Screwdriver Bak-Chek® Angle Stop with Vandal Resistant Stop Cap
Vacuum Breaker with Flush Connection
Spud Coupling and Spud Flange for 11⁄2" Top Spud
Sweat Solder Adapter with Cover Tube and Cast Wall Flange
Non-Hold-Open Handle and No External Volume Adjustment to Ensure Water Conservation
Diaphragm, Handle Packing and Vacuum Breaker Molded from PERMEX® Rubber Compound for Chloramine Resistance
ADA Compliant Metal Oscillating Non-Hold-Open Handle

Flushometer Features of Sloan 111-1.6 ESS

Vacuum Breaker with Flush Connection
Sweat Solder Adapter with Cover Tube and Cast Wall Flange
User friendly three (3) second Flush Delay
No External Volume Adjustment to Ensure Water Conservation
OPTIMA® EL-1500 Self-Adaptive Infrared Sensor with Indicator Light
I.P.S. Screwdriver Bak-Chek® Angle Stop with Vandal Resistant Stop Cap
Courtesy Flush® Override Button
High Chloramine Resistant PERMEX® Synthetic Rubber Diaphragm with Linear Filtered Bypass and Vortex Cleansing ActionTM
Diaphragm, Stop Seat and Vacuum Breaker to be molded from PERMEX® rubber compound for Chloramine resistance

NOTES

All information contained within this document subject to change without notice.
Static load tested according to the procedure outlined in Section 6.7 of ASME A112.19.2. Not recommended for bariatric use

Applications

Public Buildings & Facilities
Commercial & Industrial Buildings
Government & Military Facilities
Retail & Strip Malls
Multifamily & Mixed-Use

Downloads

Sloan Valve Co. Warranty
