ACCENTRA (formerly Yale) 1500 Series Traditional Mortise Exit Device

Name: ACCENTRA (formerly Yale) 1500 Series Traditional Mortise Exit Device
Brand: ACCENTRA Commercial
SKU: 1530-42371250
Price: 2046.88 USD
Availability: InStock

$2,046.88

$3,411.47

40% Off

Model:: 1530-42371250

Item normally ships out within 4-6 Weeks (excluding transit time).

Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.

Request for Quote

Email us your RFQ sales@americanwholesaleoutlet.com
or call us for pricing 215-279-8511
or send us a request using the form below and we will respond to you by email.

Product Name

SKU

Ask A Question

Details: ACCENTRA (formerly Yale) 1500 Series Traditional Mortise Exit Device

The 1530 is a traditional exit device integrated with ACCENTRA 8700 series mortise lock for the active leaf of pairs and single doors where both exit device and security are required. Can be installed on metal, wood or composite doors. The 8700 series mortise lock used is modified for use with exit devices only.

Features

Strong & reliable: ANSI/BHMA Certified: A156.3 Type 1, Grade 1 for long life and durability
Designed for wide stile and flush doors
Handed; specify hand
Two-piece mechanical 3/4" throw deadlocking stainless steel latchbolt
For - Single swing doors, Pairs of doors with vertical rod devices or automatic flush bolts, Metal, wood or compatible door materials

Specifications

Door Thickness: 1-3/4" (44mm) standard.
Minimum Stile Width: 4-1/2" (114mm)
Projection: 5-5/8" (143mm) active, 4-1/2" (114mm) depressed.
Latchbolt: Two piece mechanical 3/4" (19mm) deadlocking stainless steel with anti-friction insert and auxiliary dead-locking latch
Strike: 798 curved lip, non-handed standard.
Fasteners: Machine screws and wood door fasteners standard for panic hardware. Sex nuts and bolts supplied standard for fire exit hardware.
Dogging: Hex key dogging supplied standard on panic devices
UL/cUL Listed: FVSR/FVSR7 - Panic hardware, GXHX/GXHX7 - Fire exit hardware (F) (4' x 8' single, 8' x 8' pairs, 3 hr.) (4' x 9' single, 8' x 9' pairs, 1-1/2 hr.)
