ACCENTRA (formerly Yale) 6100ED Series Rim Exit Device
$888.18
$1,480.30
40% Off
As low as:
- Model:
-
6100ED
Item normally ships out within 4-6 Weeks (excluding transit time).
Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.
Request for Quote
Details: ACCENTRA (formerly Yale) 6100ED Series Rim Exit Device
With its robust, modern design and smooth, quiet operation, the ASSA ABLOY ACCENTRA 6000 Series exit device provides an attractive solution that can withstand the rigors of multi-family, retail, office and other commercial exits. The stylish, clean lines of the wide and narrow stile 6000 exit device are visually appealing and blend with any decor. With a range of mechanical and electromechanical functions available, the 6000 can be used in many types of commercial facilities, including office buildings, retail environments, and mixed-use facilities.
The 6100ED is a rim exit device to be used with single doors or pairs of doors constructed of metal, wood or composite materials. Designed for application in high-use areas, the 6100ED comes in a variety of finishes and can be combined with a variety of trims to match any desired style.
Features
- Highly durable aluminum rail design with architecturally finished touch bar.
- Heavy duty, angled end cap design protects rail, eliminates catch points and reduces damage
- Unique design provides noise reduction and smooth operation of the touch bar
- Designed for wide stile doors
- 3/4" throw deadlocking stainless steel pullman latchbolt
- Available in double cylinder function (must specify handing)
- Non-handed for easy installation
- For - Single swing doors, Pairs of doors with removable mullions, Wide stile aluminum, metal, wood or composite door materials
Specifications
- Door Thickness
- 1-3/4" (44mm) standard.
- Minimum Stile Width
- 4-1/2" (114mm)
- Projection
- 3-1/4" (83mm) active; 2-1/2" (63.5mm) dogged
- Latchbolt
- Stainless steel pullman style, 3/4" (19mm), deadlocking
- Strike(s)
- 757F standard
- Fasteners
- Machine screws or wood door screws standard for panic; sex nuts and bolts (SNB) supplied standard for fire
- Handing
- Non-handed
- ANSI/BHMA
- Certified ANSI/BHMA A156.3 Type 1 Grade 1 standard
- Dogging
- Hex key dogging standard on panic; optional cylinder dogging
Applications
- Public Buildings & Facilities
- Commercial & Industrial Buildings
- Government & Military Facilities
- Retail & Strip Malls
- Multifamily & Mixed-Use
Downloads
- Catalog
- Exit Device Parts Manual
- Installation Instructions
- 6100ED Double Cylinder Installation Instructions
- 6100 757 Strike Metal Door & Frame or Mullion Template
- 6100 793 Strike Pair of Metal Doors without Mullion Template
- 6100 757 Strike Wood or Composite Door & H.M. Frame or Mullion Template
- 6100 793 Strike Optional SNB Pair of Wood or Composite Doors w/o Mullion Template
- 6100(F) 757F Strike Metal Door & Frame or Mullion Template
- 6100(F) 757F Strike Wood or Composite Door & H.M. Frame or Mullion Template
