ACCENTRA (formerly Yale) 6130ED Series Mortise Exit Device
$1,151.24
$1,918.74
40% Off
As low as:
- Model:
-
6130EDItem normally ships out within 4-6 Weeks (excluding transit time).Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.Request for Quote
Details: ACCENTRA (formerly Yale) 6130ED Series Mortise Exit Device
The 6130ED is an exit device integrated with the ACCENTRA 8700 Series Mortise Lock for use on single doors or active leaf of a pair of doors where life safety and extra security are required. The 8700 Series Mortise Lock is modified for use with exit devices only.
Features
- Highly durable aluminum rail design with architecturally finished touch bar.
- Heavy duty, angled end cap design protects rail, eliminates catch points and reduces damage
- Unique design provides noise reduction and smooth operation of the touch bar
- Designed for wide stile and flush doors
- Handed. Specify hand (field reversible)
- Two-piece mechanical 3/4" throw deadlocking stainless steel latchbolt
- Available in double cylinder function
- For - Single swing doors, Pairs of doors with removable mullions, Wide stile aluminum, metal, wood or composite door materials
Specifications
- Door Thickness
- 1-3/4" (44mm) standard.
- Minimum Stile Width
- 4-1/2" (114mm)
- Projection
- 3-1/4" (83mm) active; 2-1/2" (63.5mm) dogged
- Latchbolt
- Two piece mechanical 3/4" (19mm) deadlocking stainless steel with anti-friction insert and auxilliary deadlocking latch
- Strike(s)
- 798 curved lip
- Fasteners
- Machine screws or wood door screws standard for panic; sex nuts and bolts (SNB) supplied standard for fire
- Handing
- Handed
- ANSI/BHM
- Certified ANSI/BHMA A156.3 Type 3 Grade 1 standards
- Dogging
- Hex key dogging standard on panic; optional cylinder dogging
Applications
- Public Buildings & Facilities
- Commercial & Industrial Buildings
- Government & Military Facilities
- Retail & Strip Malls
- Multifamily & Mixed-Use
Downloads
- Catalog
- Exit Device Parts Manual
- 6130 Installation Instructions
- 6130 Double Cylinder Latchhead Assembly Installation Instructions
- 6130 ANSI A115.1 Strike Optional SNB Pair of Wood or Composite Doors w/o Mullion Template
- 6130 ANSI A115.1 Strike Optional SNB Wood or Composite Door & H.M. Frame Template
- 6130 718 Open Back Strike Pair of Wood or Composite Doors w/o Mullion Template
- 6130 ANSI A115.1 Strike Metal Door & Frame Template
- 6130 ANSI A115.1 Strike Pair of Metal Doors w/o Mullion Template
- 6130 718 Open Back Strike Pair of Metal Doors w/o Mullion Template
