ACCENTRA (formerly Yale) 7110/7170 Surface Vertical Rod Exit Device

ACCENTRA Commercial
$2,048.24
$3,413.73
40% Off
Model:
7110/7170
Item normally ships out within 4-6 Weeks (excluding transit time).
Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.
printer Print
Email to a Friend
Request for Quote

Email us your RFQ sales@americanwholesaleoutlet.com
or call us for pricing 215-279-8511
or send us a request using the form below and we will respond to you by email.

Details: ACCENTRA (formerly Yale) 7110/7170 Surface Vertical Rod Exit Device

The 7110 is a surface vertical rod exit device to be used on wide stile or flush doors up to 8' (fire) and 10' (panic) where two-point latching is desired.

The 7170 is a surface vertical rod exit device to be used on wide stile and flush doors up to 10' where one- or two-point latching is desired. A Less Bottom Rod (LBR) option is available.

Features

  • High quality steel chassis and heavy-duty components
  • Sleek design and clean lines suit the appearance of many modern commercial buildings
  • Designed for wide stile and flush doors
  • Handed. Specify hand (field reversible)
  • Bottom deadbolt for secure latching
  • Fully adjustable roller strike (7110)
  • Interlocking top strike and latch mounting plate (7170)
  • Available less bottom rod (LBR option) (7170 only)
  • Available certified hurricane resistant (refer to local codes - not approved for LBR). Specify 7170WS
  • For - Pairs of doors, Double egress, Metal, wood or composite door materials

Specifications

Door Opening Height
Standard door height 7' (213cm), with the device centerline at 39-15/16" (101cm) from floor
Optional Heights(7110)
Up to 8' (fire) and 10' (panic) available by using rod extensions
Optional Heights(7170)
8', 9', 10'
Door Thickness
1-3/4" (44mm) standard
Minimum Stile Width
4-1/2" (114mm)
Projection
3-1/4" (83mm) active, 2-3/4" (70mm) dogged
Latchbolt Top
3/4" (19mm) throw, pullman-type with automatic deadlatching
Latchbolt Bottom
5/8" (16mm) throw deadbolt, held retracted during door swing
Vertical Rods
1/2" O.D. tubular brass, bronze or stainless steel with rod guides
Strike(7110)
Top: Roller type 791. Bottom: Flush mounted 790
Strike(7170)
Top: 726. Bottom: Flush-mounted 790
Fasteners
Machine screws and wood door fasteners standard for panic hardware. Sex nuts and bolts supplied standard for fire exit hardware
ANSI/BHMA
Certified A156.3 Type 2, Grade 1
UL/cUL (7110)
FVSR/FVSR7 - Panic hardware; GXHX/GXHX7 - Fire exit hardware (F) (8' × 8' pairs, 3 hr.)
UL/cUL (7170)
FVSR/FVSR7 - Panic hardware; GXHX/GXHX7 - Fire exit hardware (F) (8' × 10' pairs, 1-1/2 hr.) (8' × 8' pairs, 3 hr.); ZHEM -Latching hardware; ZHLA - Windstorm rated assemblies
Dogging
Hex key dogging supplied standard on panic devices

Applications

  • Public Buildings & Facilities
  • Commercial & Industrial Buildings
  • Government & Military Facilities
  • Retail & Strip Malls
  • Multifamily & Mixed-Use
