Trine 4100 Electric Strike for Cylindrical & Mortise
$366.00
$610.00
40% Off
- Model:
-
4100-42252749
Item is normally in stock and ships out within 3-5 Business days (excluding transit time).
If out of stock it can take up to 2-4 weeks (excluding transit time). Specific options may or may not increase shipping time. For any reason, if there is a delay in shipping time we will notify you. Feel free to contact us if you have any concerns.
Request for Quote
Details: Trine 4100 Electric Strike for Cylindrical & Mortise
4100 Electric Strike
We include the 4 most used faceplates to make specifying and installing easy
Covers 90%+ of Cylindrical & Mortise Lock configurations (without deadbolt), plus faceplates can be kept & used to help accomodate for door sag.
1 - 3/8" Shallow backset and Three Hour Fire Rated
4100 Features:
- BHMA Grade 1 Electric Strike -- heavy duty construction, 1,000,000+ Life cycles -- 3,250+ lbs. Holding Force
- Four popular faceplates included -- including the 4 most used faceplates in the box makes specifying and installing easy Covers 90%+ of Cylindrical & Mortise Lock configurations (without deadbolt), plus faceplates can be kept & used to help accomodate for door sag.
- 1 - 3/8" Shallow backset -- the 4100 low profile electric strike can be used in 2" fire rated frames with 1/2" sheetrock ingress
- Low Current Draw -- .240 Amp at 12DC makes it very PoE Friendly 12 & 24DC :: 12 through 24 AC. All the low voltage and amperage flexibility you need
- The included CCTS covers the gap when retrofitting the HES® 1006, Folger Adams® 712/732, and Von Duprin® 6200 Series or even Trine EN Series strikes. No more ugly trim skirts. The CCTS always matches the faceplate finish.
- Why cut for a deadbolt 100% of the time when they are only used 5% of the time.
- Patented # US20110241361
- Cutout Specification A115.1 (with Slight Jamb Modification)
Standards
- Class A, 3 Hour fire rated single door / frame configuration
- WH recognized for UL10C, Fire Tests of Door Assemblies
- UBC 7-2, Uniform building Code
- CAN4 S104, Standard Method for Fire Tests of Door Assemblies
- NFPA 252 - Issue: 1999/01/01 Standard Methods of Fire Tests of Door Assemblies
- NOTE: WH fire listing is void when using fail safe action.
- UL LISTED - 1034 Burglary Resistant
- ANSI/BHMA A156.5 - 1992 - 4-7/8" × 1-1/4" Fits
When removing the connector and using the wires direct; Red Wire is Common, Blue Wire accepts 12DC & 12-16 AC, Brown Wire accepts 24DC.
| 12DC | 0.240 A | 50 Ω | Intm./Cont. | Silent | Blue/Red |
| 24DC | 0.114 A | 210 Ω | Intm./Cont. | Silent | Brown/Red |
| 12AC | 0.210 A | 50 Ω | Intm. | Buzz | Blue/Red |
| 16AC | 0.280 A | 50 Ω | Intm. | Buzz | Blue/Red |
| 24AC | 0.420 A | 50 Ω | Intm. | Buzz | Blue/Red |
Additional Resources
4100 Electric strike - for use with Cylindrical and Mortise Locks devices
4100 Electric strike - for Cylindrical and Mortise Locks.
Trine's very low current draw electric strike that can be used with PoE (Power over Ethernet) devices. Low Current Draw ™ electric strikes use less then 300 Milliamps (.300 Amps) or around 3.6 - 3.7.Watts to activate.
This provides plenty of "cushion" for PoE based access control systems, room to run longer wires, or extra amps to run additional devices. An electric strike of this variety does not come with an Ethernet port as a remote activation like that would rarely be used and not how such a devices is commonly used.
List of Low Current Draw ™ Electric Strikes:
| Strike | Features |
|---|---|
| 4100-One Box Solution | .240 Amps @ 12DC uses 2.88 Watts || .114 Amps @ 24DC uses 2.74 Watts. |
| 4850PoE | .260 Amps @ 12DC uses 3.12 Watts. |
| 4850LCD | .135 Amps @ 24DC uses 3.24 Watts. |
| The Entire EN Series | The only UL Outdoor Rated Strikes which include the popular EN400 for Cylindrical and Mortise Locks and the EN400RP for Rim Panic Exit Devices. All strikes are -- .280 Amps @ 12DC uses 3.36 Watts & .150 Amps @ 24DC uses 3.6 Watts |
1. Easy Install
Traditionally, to use an electric strike on a PoE system a second power supply had to be run. With a Low Current Draw ™ electric strike, this is no longer necessary. It will run fromth power provided through the access control system. These electric strikes provide a power cushion which can be used any way you need.
2. Smaller Power Supplies
Low Current Draw ™ means you can use smaller power supplies and save some green. It's also peace of mind, knowing that you won't need to worry about power supply size problems or issues with amperage drop. Make your everyday installations hassle free.
| Name | Recommended Choices | |
|---|---|---|
| Cylindrical Lock |  | 4100, 4200, 400CMRP, 234X-375, 234, 478X-375, 478, 258, 258RD, 458 |
| Mortise with a Deadbolt |  | 4100DBDL |
| Mortise Lock |  | 4100, 400CMRP |
| Mortise Lock |  | 4100, 4200 |
| Dead Latch |  | 4100, 4200, 258, 258RD, 458 |
| Vertical Rod Latch |  | 275VR |
| Mortise Exit Device |  | 4100, 400CMRP |
| Rim Panic Exit Device |  | 4850, 4850PoE, 4850LCD, 4800F, 4801, 400CMRP |
| Electric Strike | Compatible Door Frames | Notes | |
|---|---|---|---|
 | 4100 | Hollow Metal Frame, Wood, Aluminum | Use the 4100RX for Raco© frames (covers the extra 1/4" gap in the frame) |
 | 4100DBDL | Hollow Metal Frame, Wood, Aluminum | Best strike for allowing deadbolt privacy with an override. |
 | 4200 | Wood, Aluminum | ONLY strike with Fascia Color Options -- Match the Fascia to your frame! |
 | 4850, 4850PoE, 4850LCD | Hollow Metal Frame, Wood, Aluminum | For wood frames use 2" long mounting screws. |
 | 4800F, 4801 | Hollow Metal Frame, Wood, Aluminum | For wood frames use 2" long mounting screws. |
| 400CMRP | Hollow Metal Frame, Wood | For wood frames use 2" long mounting screws. |
 | 275VR | Hollow Metal Frame, Wood, Aluminum | 2-3/4" wide plate. Fits in tight spots in the header. |
 | 234X-375 | Formed Sheet Metal, Wood | For wood frames use 2" long mounting screws. |
| 234 | Hollow Metal Frame, Wood | For wood frames use 2" long mounting screws. |
 | 478X-375 | Formed Sheet Metal, Aluminum, Wood | For wood frames use 2" long mounting screws. |
 | 478 | Hollow Metal Frame, Wood | |
 | 258, 258RD | Aluminum | |
 | 458 | Aluminum |
| Trine | Folger Adams | HES | Von Duprin | Adams Rite | RCI |
|---|---|---|---|---|---|
| 4200 | ---- | 5000 | 4200, 5100 | 7100, 7400 | 4 Series, 6 Series |
| 4100 | 712/712-75/732 732-75/642CYL | 4500 | 6400, 6211/6211WF | 7200 | 2164 |
| 4100DBDL | ---- | 1006CDB | 6400 | ---- | F2 Series |
| 4850 | ---- | 9400, 9600 | ---- | ---- | 0563 |
| 4800F | ---- | 9500, 9600 | 6300 | ---- | 0162F |
| 4801 | 712/712-75/732 732-75/642CYL | 9700 | ---- | ---- | ---- |
| EN400 | ---- | 1006J/7501 | 6211/6211WF | 7200 | 2114/F4114 |
| EN430 | 652SYL | 1006KD | 6210 | ---- | 2134/2334 |
| EN435 | 652RFL | 1006K | 6210 | ---- | 2124 |
| EN800 | 652RFL | 7000-783S | 6112 | 74R1 | 0161 |
| EN850 | 310-4 | 7000-789S | ---- | 74R2 | ---- |
| EN950 | 310-2 | 7505 | 6215/6226 | ---- | ---- |
| EN950W | 310-2W | ---- | ---- | ---- | ---- |
| EN960 | 310-2 3/4 | ---- | 6214/6224 | ---- | ---- |
| 323478LC | ---- | ---- | ---- | ---- | ---- |
| 234 | ---- | ---- | ---- | ---- | ---- |
| 258 | ---- | ---- | ---- | ---- | ---- |
| 458 | ---- | ---- | ---- | ---- | ---- |
| 478 | ---- | 5000/5200+501 | ---- | 7400+ | L6514+ |
| 478RD | ---- | 5000/5200+501"A" | ---- | 7401+ | L6504+ |
